LSR 系列

項目

特性

工作(zuo)溫度范圍

-40～+105℃（16-450VDC）

額定(ding)電壓(ya)范圍

16～500VDC

靜(jing)電容量容許差(cha)

± 20%（M）20℃/120HZ

漏電流(liu)

I=0.01CV或者5mA中任意一個較小值
I:漏電(dian)流（µA）、C:靜電(dian)容量(liang)（µF）、額(e)定電(dian)壓(ya)（VDC）  20℃、5分(fen)鐘值

損失角正切值

額定電壓（Vdc）

16-50V

63V-80V

100v～250V

315v～400V

420V～450V

tanδMax

0.35

0.25

0.15

0.15

0.20

反向(xiang)電(dian)壓(ya)/等(deng)效串(chuan)聯電(dian)感

2 V / 20 nH

溫(wen)度特性

靜電容(rong)量變化(hua)率 C（-25℃）/C（+20℃）≥0.7  20℃/120HZ

絕緣電(dian)阻(zu)

全部(bu)端子和容器套上的(de)絕緣套且(qie)安裝的(de)固定帶之間用DC500V的(de)絕緣電阻測定儀測出(chu)的(de)值≥101MΩ

絕緣耐壓

全(quan)部(bu)端子和容器套的絕緣套且安裝的固(gu)定帶之間施加AC2000V的電壓(ya)1分鐘未出現異常。

耐久性(xing)

在105℃環境(jing)下，不超過(guo)額(e)定電壓的(de)范圍下疊加(jia)額(e)定紋波電流，連續加(jia)載額(e)定電壓12000小時后， 待溫度(du)恢復到20℃進行測(ce)量時，應(ying)滿足以下要求。

靜電容(rong)量變化率

≤初始值的±20%

損失角正切(qie)值(zhi)

≤初始規格值的(de)200%

漏(lou)電流

≤初始規格值

高溫(wen)無(wu)負荷特性(xing)

在(zai)105℃環境下，無負荷放(fang)置500小(xiao)時(shi)后待(dai)溫度恢復到20℃，進(jin)行試驗(yan)前(qian)處(chu)理（JIS C 5101-4 4.1項） 后進(jin)行測量(liang)時(shi)，應滿足(zu)以(yi)下要求(qiu)

靜電容量變(bian)化率(lv)

≤初始(shi)值的±20%

損(sun)失角正切值

≤初(chu)始規格值的200%

漏(lou)電流

≤初始規格值

WV

cap

Case size ØD x L

ESR 120Hz,20℃

Ripple current

Par t NO.

[Vdc]

[μF]

[mm]

[mΩ]

（Ams/105℃,120Hz）

16v

82000

35*55

6

9

LSR160M5B823KA55

120000

35*70

4

12

LSR160M5B124KA70

120000

42*50

4

11.1

LSR160M5B124KV50

150000

35*80

4

14.2

LSR160M5B154KA80

150000

42*60

3

13.7

LSR160M5B154KV60

180000

35*100

3

17

LSR160M5B184KAA0

180000

42*70

3

15.8

LSR160M5B184KV70

180000

42*80

3

15

LSR160M5B184KV80

220000

42*90

2

19.1

LSR160M5B224KV90

220000

50*70

2

17.7

LSR160M5B224KC70

270000

42*105

2

21.1

LSR160M5B274KVA5

270000

50*80

2

20.6

LSR160M5B274KC80

390000

50*100

1

27

LSR160M5B394KCA0

470000

65*80

1

35.6

LSR160M6C474KD80

560000

65*100

1

42.1

LSR160M6C564KDA0

820000

65*130

1

56.5

LSR160M6C824KDD0

820000

76*100

1

44.1

LSR160M6C824KEA0

1000000

76*115

1

46.5

LSR160M6CA5KEB5

1200000

76*145

1

50.8

LSR160M6CC5KEE5

1500000

76*170

1

53.5

LSR160M6C155KE70

1800000

89*145

1

57.3

LSR160M6C185KFE5

2200000

76*225

1

61

LSR160M6C225KEN0

2200000

89*170

1

60.4

LSR160M6C225KFH0

2700000

89*220

1

67.1

LSR160M6C275KFN0

3300000

89*230

1

68.3

LSR160M6C335KFM0

25v

33000

35*55

14

5.9

LSR250M5B333KA55

47000

35*70

9

7.8

LSR250M5B473KA70

47000

42*50

9

7.2

LSR250M5B473KV50

56000

35*80

8

9

LSR250M5B563KA80

68000

42*60

7

9.5

LSR250M5B683KV60

68000

35*100

5

11.9

LSR250M5B683KAA0

68000

42*70

7

10

LSR250M5B683KV70

82000

42*80

5

10.5

LSR250M5B823KV80

82000

42*90

7

11

LSR250M5B823KV90

100000

50*70

4

12.3

LSR250M5B104KC70

120000

42*105

4

14.6

LSR250M5B124KVA5

120000

50*80

4

14.2

LSR250M5B124KC80

150000

50*100

3

17.3

LSR250M5B154KCA0

180000

65*80

3

22.4

LSR250M6C184KD80

270000

65*100

2

29.8

LSR250M6C274KDA0

330000

76*100

1

28.5

LSR250M6C334KEA0

50v

27000

50*70

8

8

LSR500M5B273KC70

33000

42*100

7

7

LSR500M5B333KVA0

39000

50*90

7

10

LSR500M5B393KC90

47000

65*70

4

13.1

LSR500M6C473KD70

68000

65*85

4

16.5

LSR500M6C683KD85

82000

76*90

3

17.1

LSR500M6C823KE90

100000

65*120

3

22.1

LSR500M6C104KDC0

120000

76*115

2

20.3

LSR500M6C124KEB5

150000

76*130

2

24.6

LSR500M6C154KED0

180000

76*150

2

28.6

LSR500M6C184KEF5

220000

89*140

1

35.1

LSR500M6C224KFE0

270000

76*220

1

38.8

LSR500M6C274KEN0

330000

89*200

1

48.6

LSR500M6C334KFO0

390000

89*210

1

51.6

LSR500M6C394KFP0

470000

89*230

1

56.5

LSR500M6C474KFM0

63v

8200

35*55

35

3.7

LSR630M5B822KA55

12000

42*50

24

4.6

LSR630M5B123KV50

15000

35*70

19

5.5

LSR630M5B153KA70

18000

35*80

16

6.3

LSR630M5B183KA80

18000

42*60

16

6.1

LSR630M5B183KV60

18000

35*100

16

6.9

LSR630M5B183KAA0

22000

42*70

13

7.1

LSR630M5B223KV70

22000

42*80

13

6.8

LSR630M5B223KV80

27000

50*70

11

8

LSR630M5B273KC70

27000

42*105

11

8.6

LSR630M5B273KVA5

33000

50*80

9

9.3

LSR630M5B333KC80

33000

42*105

9

9.5

LSR630M5B333KVA5

39000

50*100

7

11

LSR630M5B393KCA0

47000

65*80

6

14.5

LSR630M6C473KD80

68000

65*100

4

19

LSR630M6C683KDA0

82000

76*100

3

18

LSR630M6C823KEA0

100000

65*130

3

25.5

LSR630M6C104KDD0

120000

76*115

2

22.9

LSR630M6C124KEB5

150000

76*145

2

28.1

LSR630M6C154KEE5

180000

76*170

2

32.4

LSR630M6C184KE70

220000

89*145

1

38.3

LSR630M6C224KFE5

220000

76*225

1

40.8

LSR630M6C224KEN0

270000

89*170

1

44.8

LSR630M6C274KFH0

330000

89*220

1

54.9

LSR630M6C334KFN0

390000

89*230

1

60.9

LSR630M6C394KFM0

80v

6800

35*55

47

3.2

LSR800M5B682KA55

8200

42*50

39

3.8

LSR800M5B822KV50

10000

35*70

32

4.2

LSR800M5B103KA70

12000

35*80

27

4.6

LSR800M5B123KA80

12000

42*60

27

4.7

LSR800M5B123KV60

15000

35*100

21

6

LSR800M5B153KAA0

15000

42*70

21

5.6

LSR800M5B153KV70

15000

42*80

21

5.3

LSR800M5B153KV80

160v

3900

42*80

29

4.6

LSR161M5B392KV80

4700

42*100

24

5.4

LSR161M5B472KVA0

4700

50*70

24

5.7

LSR161M5B472KC70

5600

50*80

20

6.1

LSR161M5B562KC80

6800

42*105

16

6.9

LSR161M5B682KVA5

8200

50*100

14

8.1

LSR161M5B822KCA0

8200

65*80

14

9.7

LSR161M6C822KD80

12000

65*100

9

12.8

LSR161M6C123KDA0

18000

65*130

6

13.7

LSR161M6C183KDD0

18000

76*100

6

17.1

LSR161M6C183KEA0

18000

76*115

6

14.3

LSR161M6C183KEB5

27000

76*145

4

19.1

LSR161M6C273KEE5

27000

76*170

4

20.1

LSR161M6C273KE70

39000

89*145

3

25.9

LSR161M6C393KFE5

47000

76*225

2

30.2

LSR161M6C473KEN0

47000

89*170

2

30

LSR161M6C473KFH0

56000

89*220

2

36.3

LSR161M6C563KFN0

68000

89*230

2

40.7

LSR161M6C683KFM0

200v

1500

35*50

63

2.8

LSR201M5B152KA50

1800

35*70

52

2.6

LSR201M5B182KA70

2200

42*70

41

3.1

LSR201M5B222KV70

2700

42*70

33

4.1

LSR201M5B272KV70

3300

42*100

27

4.5

LSR201M5B332KVA0

3900

50*60

28

5

LSR201M5B392KC60

4700

50*80

14

5.2

LSR201M5B472KC80

5600

50*90

16

7

LSR201M5B562KC90

6800

65*70

16

8.2

LSR201M6C682KD70

8200

65*90

11

10.3

LSR201M6C822KD90

10000

65*105

10

11.1

LSR201M6C103KDA5

12000

65*120

7

11.6

LSR201M6C123KDC0

15000

76*105

5

12.6

LSR201M6C153KEA5

18000

76*130

4

14.2

LSR201M6C183KED0

22000

76*145

4

19.3

LSR201M6C223KEE5

27000

76*190

3

21.6

LSR201M6C273KEK0

39000

89*200

2

26.3

LSR201M6C393KFO0

47000

89*230

1

28.8

LSR201M6C473KFM0

250v

1200

35*55

80

2.4

LSR251M5B122KA55

1500

35*70

64

3

LSR251M5B152KA70

1500

42*55

64

2.8

LSR251M5B152KV55

1800

35*80

53

3.5

LSR251M5B182KA80

1800

42*70

53

3.3

LSR251M5B182KV70

2200

42*80

43

4.1

LSR251M5B222KV80

2700

35*100

35

4.4

LSR251M5B272KAA0

2700

42*80

35

4.1

LSR251M5B272KV80

3300

42*90

29

4.9

LSR251M5B332KV90

3300

50*70

29

5.2

LSR251M5B332KC70

3900

50*80

24

5.5

LSR251M5B392KC80

3900

42*105

24

5.7

LSR251M5B392KVA5

400v

3300

65*80

39

5.8

LSR401M6C332KD80

3900

65*100

33

6.8

LSR401M6C392KDA0

4700

65*120

30

6.8

LSR401M6C472KDC0

5600

76*100

23

8.9

LSR401M6C562KEA0

6800

76*115

19

8.2

LSR401M6C682KEB5

8200

76*145

16

9.8

LSR401M6C822KEE5

10000

76*170

13

11.4

LSR401M6C103KE70

12000

89*145

11

13.4

LSR401M6C123KFE5

15000

76*225

8

16

LSR401M6C153KEN0

15000

89*170

8

15.8

LSR401M6C153KFH0

18000

89*220

7

19.2

LSR401M6C183KFN0

22000

89*230

7

22.1

LSR401M6C223KFM0

450v

470

35*55

237

1.4

LSR451M5B470KA55

560

35*70

199

1.7

LSR451M5B560KA70

560

42*55

199

1.7

LSR451M5B560KV55

680

35*80

164

1.7

LSR451M5B680KA80

820

42*70

136

2

LSR451M5B820KV70

820

35*100

136

2.1

LSR451M5B820KAA0

1000

42*80

111

2.2

LSR451M5B102KV80

1000

42*70

111

2.4

LSR451M5B102KV70

1200

42*90

93

2.9

LSR451M5B122KV90

1500

50*80

74

3.2

LSR451M5B152KC80

1500

42*105

74

3.3

LSR451M5B152KVA5

1800

50*100

62

3.8

LSR451M5B182KCA0

2200

65*80

51

5

LSR451M6C222KD80

2700

65*100

41

6.1

LSR451M6C272KDA0

3900

65*130

29

8.1

LSR451M6C392KDD0

3900

76*100

29

6.3

LSR451M6C392KEA0

4700

76*115

24

7.3

LSR451M6C472KEB5

5600

76*145

20

8.7

LSR451M6C562KEE5

25v

330000

65*130

1

36.4

LSR250M6C334KDD0

390000

65*130

1

32.6

LSR250M6C394KDD0

560000

76*145

1

42.7

LSR250M6C564KEE5

560000

76*170

1

45

LSR250M6C564KE70

820000

89*145

1

58.2

LSR250M6C824KFE5

820000

89*145

1

62

LSR250M6C824KFE5

820000

89*170

1

61.5

LSR250M6C824KFH0

1200000

89*220

1

82.6

LSR250M6CC5KFN0

1500000

89*230

1

94

LSR250M6C155KFM0

35/40v

18000

35*55

21

4.7

LSR400M5B183KA55

22000

42*50

17

5.3

LSR400M5B223KV50

27000

35*70

14

6.4

LSR400M5B273KA70

33000

35*80

12

7.4

LSR400M5B333KA80

33000

42*60

12

7.2

LSR400M5B333KV60

39000

35*100

10

8.9

LSR400M5B393KAA0

39000

42*70

10

8.2

LSR400M5B393KV70

39000

42*80

10

7.8

LSR400M5B393KV80

56000

50*70

7

10

LSR400M5B563KC70

56000

42*90

7

10.8

LSR400M5B563KV90

68000

50*80

6

11.6

LSR400M5B683KC80

68000

42*105

6

11.8

LSR400M5B683KVA5

82000

50*100

5

13.8

LSR400M5B823KCA0

100000

65*80

4

18.3

LSR400M6C104KD80

150000

65*100

3

24.4

LSR400M6C154KDA0

180000

76*100

2

23.1

LSR400M6C184KEA0

180000

65*130

2

29.6

LSR400M6C184KDD0

220000

76*115

2

26.9

LSR400M6C224KEB5

270000

76*145

1

32.6

LSR400M6C274KEE5

330000

76*170

1

38

LSR400M6C334KE70

470000

89*145

1

48.5

LSR400M6C474KFE5

470000

76*225

1

51.6

LSR400M6C474KEN0

560000

89*170

1

55.8

LSR400M6C564KFH0

680000

89*220

1

68.3

LSR400M6C684KFN0

680000

89*230

1

69.6

LSR400M6C684KFM0

50v

6800

35*50

38

2.5

LSR500M5B682KA50

8200

35*50

33

2.8

LSR500M5B822KA50

10000

42*40

22

3.1

LSR500M5B103KV40

15000

42*50

18

3.3

LSR500M5B153KV50

15000

35*60

16

3.4

LSR500M5B153KA60

18000

42*60

14

6.1

LSR500M5B183KV60

22000

42*70

10

6.5

LSR500M5B223KV70

80v

18000

42*90

18

6.2

LSR800M5B183KV90

18000

50*70

18

6.2

LSR800M5B183KC70

22000

42*105

14

7.9

LSR800M5B223KVA5

22000

50*80

14

7.2

LSR800M5B223KC80

27000

50*100

12

8.7

LSR800M5B273KCA0

39000

65*80

8

12.6

LSR800M6C393KD80

47000

65*100

7

15

LSR800M6C473KDA0

68000

65*130

5

15.7

LSR800M6C683KDD0

68000

76*100

5

19.7

LSR800M6C683KEA0

82000

76*115

4

18

LSR800M6C823KEB5

100000

76*145

3

21.7

LSR800M6C104KEE5

120000

76*170

3

25.1

LSR800M6C124KE70

150000

89*145

2

30

LSR800M6C154KFE5

180000

76*225

2

35

LSR800M6C184KEN0

180000

89*170

2

34.3

LSR800M6C184KFH0

220000

89*220

1

42.6

LSR800M6C224KFN0

270000

89*230

1

48

LSR800M6C274KFM0

100v

3300

35*55

48

3.1

LSR101M5B332KA55

4700

35*70

34

4.1

LSR101M5B472KA70

4700

42*55

34

3.8

LSR101M5B472KV55

5600

35*80

28

4.7

LSR101M5B562KA80

5600

42*70

28

4.6

LSR101M5B562KV70

6800

35*100

23

5.7

LSR101M5B682KAA0

6800

42*70

23

5.3

LSR101M5B682KV70

8200

42*80

19

5.5

LSR101M5B822KV80

10000

50*70

16

6.5

LSR101M5B103KC70

10000

42*105

16

7.1

LSR101M5B103KVA5

12000

42*120

13

7.7

LSR101M5B123KVC0

12000

50*80

13

7.5

LSR101M5B123KC80

15000

50*100

11

9.2

LSR101M5B153KCA0

18000

65*80

9

12.1

LSR101M6C183KD80

22000

65*100

7

14.5

LSR101M6C223KDA0

27000

76*100

6

13.9

LSR101M6C273KEA0

33000

65*130

5

19.6

LSR101M6C333KDD0

39000

76*115

4

17.6

LSR101M6C393KEB5

47000

76*145

3

21.1

LSR101M6C473KEE5

56000

76*170

3

24.2

LSR101M6C563KE70

68000

89*145

2

28.6

LSR101M6C683KFE5

82000

76*225

2

33.4

LSR101M6C823KEN0

82000

89*170

2

33.1

LSR101M6C823KFH0

120000

89*220

1

44.5

LSR101M6C124KFN0

120000

89*230

1

45.3

LSR101M6C124KFM0

160v

1800

35*55

62

2.8

LSR161M5B182KA55

2200

35*70

51

3.4

LSR161M5B222KA70

2200

42*55

51

3.1

LSR161M5B222KV55

2700

35*80

41

3.9

LSR161M5B272KA80

3300

42*70

34

4.2

LSR161M5B332KV70

3900

35*100

29

5.2

LSR161M5B392KAA0

250v

5600

50*100

17

5.7

LSR251M5B562KCA0

5600

65*80

17

7.2

LSR251M6C562KD80

8200

65*100

12

8.7

LSR251M6C822KDA0

10000

65*120

12

11.4

LSR251M6C103KDC0

12000

76*100

8

12.1

LSR251M6C123KEA0

15000

76*115

6

14.1

LSR251M6C153KEB5

18000

76*115

6

14.1

LSR251M6C183KEB5

18000

76*145

5

16.8

LSR251M6C183KEE5

27000

76*170

5

17.7

LSR251M6C273KE70

27000

89*145

4

23.2

LSR251M6C273KFE5

33000

76*225

4

24.5

LSR251M6C333KEN0

39000

89*220

2

32.7

LSR251M6C393KFN0

39000

89*230

2

33.3

LSR251M6C393KFM0

350v

680

35*55

141

1.8

LSR351M5B680KA55

1000

35*70

96

2.3

LSR351M5B102KA70

1200

42*55

80

2.8

LSR351M5B122KV55

1200

35*80

80

2.7

LSR351M5B122KA80

1500

35*100

64

3

LSR351M5B152KAA0

1500

42*80

64

3.4

LSR351M5B152KV80

1800

42*90

53

3.6

LSR351M5B182KV90

1800

50*70

53

3.8

LSR351M5B182KC70

2200

50*80

43

4.2

LSR351M5B222KC80

2200

42*105

43

4.3

LSR351M5B222KVA5

2700

50*100

35

5

LSR351M5B272KCA0

3900

65*80

24

7.2

LSR351M6C392KD80

4700

65*100

20

8.6

LSR351M6C472KDA0

5600

76*100

17

8.2

LSR351M6C562KEA0

6800

65*130

14

11.5

LSR351M6C682KDD0

6800

76*115

14

9.5

LSR351M6C682KEB5

8200

76*145

12

11.4

LSR351M6C822KEE5

10000

76*170

10

13.2

LSR351M6C103KE70

12000

89*145

8

15.5

LSR351M6C123KFE5

15000

76*225

6

18.4

LSR351M6C153KEN0

15000

89*170

6

18.3

LSR351M6C153KFH0

18000

89*200

5

22.2

LSR351M6C183KFO0

22000

89*230

5

22.6

LSR351M6C223KFM0

400v

560

35*55

227

1.4

LSR401M5B560KA55

680

42*55

187

1.7

LSR401M5B680KV55

820

35*70

155

1.8

LSR401M5B820KA70

1000

35*80

127

2.2

LSR401M5B102KA80

1000

42*70

127

2.2

LSR401M5B102KV80

1200

35*100

106

2.5

LSR401M5B122KAA0

1200

42*80

106

2.4

LSR401M5B122KV80

1500

42*90

85

2.8

LSR401M5B152KV90

1500

50*70

85

3

LSR401M5B152KC70

1800

50*80

71

3.3

LSR401M5B182KC80

1800

42*105

71

3.3

LSR401M5B182KVA5

2200

50*100

58

3.9

LSR401M5B222KCA0

450v

6800

76*170

16

10.1

LSR451M6C682KE70

8200

89*145

14

11.9

LSR451M6C822KFE5

10000

76*225

11

13.9

LSR451M6C103KEN0

12000

89*170

9

15.1

LSR451M6C123KFH0

15000

89*210

7

18.8

LSR451M6C153KFP0

18000

89*230

5

19.1

LSR451M6C183KFM0

500v

390

35*55

286

1.3

LSR501M5B390KA55

470

42*55

237

1.5

LSR501M5B470KV55

560

35*70

199

1.7

LSR501M5B560KA70

680

35*80

164

2

LSR501M5B680KA80

680

42*60

164

1.9

LSR501M5B680KV60

820

35*100

136

2.2

LSR501M5B820KAA0

820

42*70

136

2.1

LSR501M5B820KV70

1000

50*70

111

2.7

LSR501M5B102KC70

1200

42*90

93

2.7

LSR501M5B122KV90

1200

50*80

93

2.8

LSR501M5B122KC80

1500

50*90

60

3.5

LSR501M5B152KC90

2200

65*80

51

5

LSR501M6C222KD80

2700

65*100

41

6.1

LSR501M6C272KDA0

3300

76*100

34

7.3

LSR501M6C332KEA0

3900

65*130

29

6.4

LSR501M6C392KDD0

4700

76*115

24

7.3

LSR501M6C472KEB5

5600

76*145

20

8.7

LSR501M6C562KEE5

6800

76*170

16

10.1

LSR501M6C682KE70

8200

89*145

14

11.9

LSR501M6C822KFE5

10000

76*220

11

13.9

LSR501M6C103KEN0

12000

76*230

9

15.1

LSR501M6C123KEM0

15000

89*200

7

18.8

LSR501M6C153KFO0

15000

89*230

7

19.1

LSR501M6C153KFM0

18000

89*230

5

20.3

LSR501M6C183KFM0

頻率(lv)（HZ）

50

120

300

1K

3K

10K

50K

16～50VDC

0.95

1.00

1.03

1.05

-

1.09

1.12

63～80VDC

0.90

1.00

1.06

1.10

-

1.18

1.22

100～250VDC

0.80

1.00

1.12

1.22

-

1.30

1.33

350～500VDC

0.80

1.00

1.20

1.50

1.60

-

-
